Rexnord 1873TAB SideGrip™ Side-flexing, Material: Tan Low Friction, Width: 3.75in, Pitch: 1.5in - 81426257
Part #:10145391
Catalog #:81426257
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Straight or Side-Flex: | Side-flexing | Chain Width (in): | 3.75 in |
| Chain Material Description: | Tan Low Friction | Chain Material: | LF |
| Gripper Material: | EPDM | Chain Width (mm): | 95.3 mm |
| Base Chain Material: | Stainless Steel | Gripper Hardness: | 50 Shore A |
| Flight Thickness (mm): | 4 mm | Chain Number: | 1873TAB SideGrip™ |
| Chain Strength (N): | 3,330 N | Surface Type: | SideGrip™ |
| Chain Pitch (in): | 1.5 in | Gripper Color: | White |
| Chain Pitch (mm): | 38.1 mm | Curve Retention Type: | TAB |
| Gripper Style: | D | Series: | TableTop 1873 Series Side-flexing Chain |
| Chain Strength (lb): | 750 lb | Flight Thickness (in): | 0.16 in |
| Chain Width Measurement System: | Imperial |
General Specifications
| Weight: | 0.32 LB | HTC: | 8431390010 |
| Country of Origin: | Mexico |
