Rexnord 1873TAB SuperGrip™ Side-flexing SuperGrip™, Material: Tan Low Friction, Width: 7.5in, Pitch: 1.5in - L1873648142
Part #:10177531
Catalog #:L1873648142
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Pitch (in): | 1.5 in | Chain Strength (lb): | 1,000 lb |
| Chain Pitch (mm): | 38.1 mm | Surface Type: | SuperGrip™ |
| Straight or Side-Flex: | Side-flexing | Flight Thickness (in): | 0.24 in |
| Curve Retention Type: | TAB | Chain Number: | 1873TAB SuperGrip™ |
| Chain Material Description: | Tan Low Friction | Base Chain Material: | Steel |
| Series: | TableTop 1873 Series Side-flexing Chain | Chain Width (in): | 7.5 in |
| Chain Width Measurement System: | Imperial | Number of SuperGrip/RubberTop Rows: | 1 Row |
| Chain Material: | LF | Chain Width (mm): | 190.5 mm |
| SG/RT Spacing (Pitches): | Every Pitch | Chain Strength (N): | 4,440 N |
| Flight Thickness (mm): | 6.1 mm |
General Specifications
| Weight: | 0.08 LB | HTC: | 8431390010 |
| Country of Origin: | Mexico |
