Rexnord 770TAB Side-flexing Solid Top, Material: Silver Platinum Series, Width: 3.25in, Pitch: 1in - 81431351
Part #:10145633
Catalog #:81431351
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Chain Strength (lb): | 425 lb | Flight Thickness (in): | 0.16 in |
| Chain Width (mm): | 82.6 mm | Chain Pitch (mm): | 25.4 mm |
| Rod/Pin Material: | Stainless Steel | Straight or Side-Flex: | Side-flexing |
| Surface Type: | Solid Top | Curve Retention Type: | TAB |
| Chain Material: | PS | Series: | TableTop 770 Series Side-flexing Chain |
| Chain Number: | 770TAB | Chain Pitch (in): | 1 in |
| Chain Width Measurement System: | Imperial | Chain Strength (N): | 1,887 N |
| Chain Material Description: | Silver Platinum Series | Chain Width (in): | 3.25 in |
| Flight Thickness (mm): | 4 mm |
General Specifications
| Weight: | 0.07 LB | HTC: | 3926909989 |
| Country of Origin: | Mexico |
