Rexnord 882TAB Side-flexing Solid Top, Material: Black Wear Resistant, Width: 3.25in, Pitch: 1.5in - 81403692
Part #:10187469
Catalog #:81403692
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Surface Type: | Solid Top | Series: | TableTop 882 Series Side-flexing Chain |
| Chain Width (in): | 3.25 in | Chain Strength (lb): | 750 lb |
| Curve Retention Type: | TAB | Chain Strength (N): | 3,330 N |
| Flight Thickness (mm): | 4.8 mm | Rod/Pin Material: | Stainless Steel |
| Chain Material: | BWR | Chain Material Description: | Black Wear Resistant |
| Chain Width (mm): | 82.6 mm | Chain Number: | 882TAB |
| Chain Pitch (mm): | 38.1 mm | Flight Thickness (in): | 0.19 in |
| Chain Pitch (in): | 1.5 in | Chain Width Measurement System: | Imperial |
| Straight or Side-Flex: | Side-flexing |
General Specifications
| Weight: | 0.15 LB | HTC: | 3926906090 |
| Country of Origin: | Mexico |
