System Plast 815 Straight Running Solid Top, Material: 0, Width: 6in, Pitch: 1.5in - SSE815-K600
Part #:10013
Catalog #:SSE815-K600
KEY FEATURES
- High performance stainless steel, specially developed for high speed and heavy duty applications.
- Offers excellent corrosion resitance and highest surface hardness.
- Extremely flat and best surface finish.
- High corrosion and wear resistance.
- Highest ultimate yield loading capability.
- Typically used in pressureless combiners and excessively long conveyors.
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Flight Thickness (in): | 0.12 in | Series: | TableTop 815 Series Chain |
| Product Line: | Conveying Chains and Belts | Product Group: | Chain |
| Product Type: | Straight Running | Chain Material: | SSE |
| Max Working Load (N): | 6,000 N | Chain Width (in): | 6 in |
| Flight Thickness (mm): | 3.1 mm | Chain Width Measurement System: | Imperial |
| Chain Width (mm): | 152.4 mm | Chain Pitch (mm): | 38.1 mm |
| Weight (lb/ft): | 2.8 lb/ft | Chain Pitch (in): | 1.5 in |
| Finish (μm): | 0.3 | Straight or Side-Flex: | Straight Running |
| Chain Number: | 815 | Weight (kg/m): | 4.2 kg/m |
| Surface Type: | Solid Top | Max Working Load (lb): | 1,350 lb |
| Rod/Pin Material: | SPM |
General Specifications
| UPC: | 726166185022 | Weight: | 2.81 LB |
| HTC: | 7315.12.0080 | Country of Origin: | Germany |
