LEESON General Purpose Motor, 0.50 & 0.50 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190-208/380-415 V, 3600 & 3000 RPM, 56 Frame, TEFC - LM24165
Part #:LM24165
Catalog #:LM24165
Model #:SRF2S0.5T61
KEY FEATURES
- Standard, EPAct efficient ratings
- Inverter-rated; Continuous duty
- Class B insulation systems – 42, 48 and 56 frames
- Shielded ball bearings for direct coupled applications Contact your local sales office for belted load applications
- Dynamically balanced rotors
- Dynamically balanced rotors
- Torques exceed NEMA performance standards; UL recognized and CSA certified
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Nameplate Specifications
| Phase: | 3 | Output HP: | 0.50 & 0.50 Hp |
| Output KW: | 0.37 & 0.37 kW | Voltage: | 230/460 & 190-208/380-415 V |
| Speed: | 3450 & 2850 rpm | Service Factor: | 1.15 & 1.0 |
| Frame: | 56 | Enclosure: | Totally Enclosed Fan Cooled |
| Thermal Protection: | No Protection | Efficiency: | 66 % |
| Ambient Temperature: | 40 °C | Frequency: | 60 & 50 Hz |
| Current: | 2.2/1.1 & 2.2-2.2/1.1-1.1 A | Power Factor: | 69.7 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | B | KVA Code: | P |
| Drive End Bearing Size: | 203 | Opp Drive End Bearing Size: | 203 |
| UL: | Recognized | CSA: | Y |
| CE: | N | IP Code: | 43 |
| Number of Speeds: | 1 |
Technical Specifications
| Electrical Type: | Squirrel Cage Induction Run | Starting Method: | Across The Line |
| Poles: | 2 | Rotation: | Reversible |
| Resistance Main: | 8.34 Ohms | Mounting: | Rigid Base |
| Motor Orientation: | Horizontal | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | NEMA 56 | Overall Length: | 11.82 in |
| Frame Length: | 6.56 in | Shaft Diameter: | 0.625 in |
| Shaft Extension: | 1.88 in | Assembly/Box Mounting: | F1 ONLY |
General Specifications
| UPC: | 691720020555 | Weight: | 26.00 LB |
| Packaged Length: | 16.38 IN | Packaged Width: | 10.50 IN |
| Packaged Height: | 8.12 IN | Country of Origin: | Mexico |
Speed Characteristics
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | Torque (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Locked-Rotor | 8.00 | 727.0 | 3.00 | 395.0 | 0 | 76.5 | 0.50 | |
| 1/3 | 7.60 | 691.0 | 2.60 | 342.0 | 900 | 0.50 | ||
| Pull-Up | 7.20 | 655.0 | 2.70 | 355.0 | 1,500 | 0.50 | ||
| Full Load | 1.10 | 100.0 | 0.76 | 100.0 | 3,450 | 0.50 | ||
| 2/3 | 6.80 | 618.0 | 3.20 | 421.0 | 2,100 | 0.50 | ||
| Break-Down | 5.20 | 473.0 | 3.80 | 500.0 | 2,600 | 85.5 | 0.50 | |
| No Load | 0.68 | 62.0 | 0.00 | 0.0 | 3,600 | 0.50 |
Load Characteristics
| % of Rated Load | 0 % | 25 % | 50 % | 75 % | 100 % | 115 % | 125 % | 130 % | 150 % | 175 % |
| Current (Amps) | 0.68 | 0.70 | 0.80 | 1.00 | 1.10 | 1.12 | 1.15 | 1.20 | 1.30 | 1.40 |
| Rated Output (KW) | 0.13 | 0.23 | 0.33 | 0.43 | 0.55 | 0.60 | 0.66 | 0.70 | 0.77 | 1.00 |
| Efficiency (%) | 0.0 | 40.5 | 56.5 | 64.5 | 66.0 | 69.0 | 71.0 | 72.0 | 72.5 | 73.0 |
| Power Factor (%) | 24.5 | 40.0 | 53.0 | 63.5 | 69.7 | 75.0 | 76.5 | 78.0 | 81.0 | 83.5 |
| Speed (RPM) | 3,600 | 3,573 | 3,555 | 3,520 | 3,450 | 3,445 | 3,440 | 3,435 | 3,420 | 3,410 |
| Temp. Rise @ FL | 0.0 | 0.0 | 0.0 | 0.0 | 35.0 | 50.0 | 65.0 | 70.0 | 0.0 | 0.0 |
| Torque (ft-lbs) | 0.00 | 0.19 | 0.37 | 0.56 | 0.76 | 0.90 | 0.94 | 0.98 | 1.10 | 1.30 |
