Rex 2858*300 Engineered Steel Chains - 2858*300
Part #:10520646
Catalog #:2858*300
How can we improve our Product Information?
Talk to one of our expert sales professionals about how this brand can efficiently power your business.
Product Specifications
Technical Specifications
| Plate Depth (in): | 2.25 in | Chain Category: | Elevator |
| Roller Style: | Non-Flange | Product Type: | Asphalt Elevator With Rollers |
| Sprocket Unit: | 2858 | Rated Working Load (lb/ft): | 7,200 lb/ft |
| Plate Style: | Straight | Series: | Welded Chains |
| Minimum Tensile Strength (lbs): | 57,000 lb | Base Catalog No: | 2858 |
| Chain Sub-Category: | Asphalt Chain | Plate Thickness (in): | 0.38 in |
| Roller Diameter (in): | 1.63 in | Chain Pitch (in): | 4.083 in |
| Overall Width/Pin Length (in): | 4.37 in | Width Between Outer Plates (in): | 2 in |
| Material: | Carbon Steel | Product: | Hard Face Drag |
| Pin Diameter (in): | 0.75 in |
General Specifications
| UPC: | 793699632972 | Weight: | 13.00 LB |
| Packaged Length: | 88.17 IN | Packaged Width: | 88.17 IN |
| Packaged Height: | 35.27 IN | Country of Origin: | United States of America |
