Browning Steel Rough Bore HPT Chain Sprocket - PB14MCS-33-68

Part #:2766913

Catalog #:PB14MCS-33-68

Key Features Product Specs

Add to Compare

Sorry, this item is no longer available. Contact engineering ([email protected]) for more information or possible solutions.

Compare Product

KEY FEATURES

HPT Chain Synchronous pulley, minimum plain bore
High performance compact design
Well suited for high-torque applications; under 500 RPM

How can we improve our Product Information?

Resource Center

Installation Manual

Talk to one of our expert sales professionals about how this brand can efficiently power your business.

Product Specifications

Technical Specifications
General Specifications

Technical Specifications

Number of teeth:	33	Flange (mm):	164.211 mm
Width (mm):	68 mm	Product Type:	HPT Chain Sprocket
Bushing:	MPB	Bore Type:	Rough Bore
Bore (Max) (mm):	88.9 mm	Outside Diameter (mm):	144.272 mm
Pitch Diameter (mm):	147.066 mm	Material:	Steel
Bore (Min) (mm):	25.4 mm	Belt Section:	14M

General Specifications

UPC:	662460616575	Weight:	24.59 LB
Packaged Length:	7.20 IN	Packaged Width:	7.50 IN
Packaged Height:	5.40 IN	HTC:	8483.50.9080
Country of Origin:	United States of America
