Browning Steel Bushed Bore HPT Sprocket - B358M30TL

Part #:2762904

Catalog #:B358M30TL

Key Features Product Specs

Add to Compare

Sorry, this item is no longer available. Contact engineering ([email protected]) for more information or possible solutions.

Compare Product

KEY FEATURES

HPT Synchronous pulley, bushed to fit taper lock bushing
Ideal for compact drive footprints
Well suited for applications over 500 RPM

How can we improve our Product Information?

Resource Center

Installation Manual

Talk to one of our expert sales professionals about how this brand can efficiently power your business.

Product Specifications

Technical Specifications
General Specifications

Technical Specifications

Flange (mm):	100.0252 mm	Width (mm):	30 mm
Number of teeth:	35	Product Type:	HPT Sprocket
Bushing:	1610	Bushing Type:	Taper Bore
Bore Type:	Bushed	Bore (Min) (mm):	12.7 mm
Belt Section:	8M	Pitch Diameter (mm):	89.1286 mm
Bore (Max) (mm):	41.275 mm	Material:	Steel
Outside Diameter (mm):	87.757 mm

General Specifications

UPC:	662460609850	Weight:	2.00 LB
HTC:	8483.50.9080	Country of Origin:	United States of America
