Cylindrical Bearings for heavy-duty trucks and off-highway construction equipment

Heavy-duty trucks and off-highway construction equipment operate under demanding conditions. Equipment found in these applications typically comes with very high warranty periods. To generate quality performance, properly selecting and designing for an application are keys to success. That goes for every component, no matter how big or how small.

Bearings

You can find bearings in all sorts of equipment and machinery. Bearings, which reduce friction and transfer motion, come in different shapes and sizes, depending on the application. Cylindrical roller bearings have cylindrical-shaped rolling elements. These types of bearings are usually found in the transmissions and axles of heavy-duty trucks and construction equipment.

Cylindrical Roller Bearings

Regal Rexnord offers many types of cylindrical roller bearings, including:

• A full line of needle roller bearings and ISO boundary plan cylindrical roller bearings under the Rollway® brand
• ABMA boundary plan cylindrical roller bearings under the Link-Belt® brand

Our product offerings include several dimensional series bearings ranging from 30mm bores up to 440mm bores. Other options include multiple inner race and outer race configurations. These configurations accommodate all application and assembly requirements. They’re available in the form of separable inner race, separable outer race, and non-separable designs.

Custom Roller Bearing Changes

Many applications are well-suited for the standard catalog roller bearings. Other applications require bearings with extra features or changed specifications. When an application has unique needs, Regal Rexnord can fully customize the bearing. Custom designs can include special envelope (bore, o.d. and width) dimensions or component configuration.

Regal Rexnord can also perform internal design modifications that can improve the bearing's operation for given specific conditions. These modifications will impact a bearing's performance. For instance, changing the roller crown radius design helps fine-tune the bearing for maximum load-carrying. Another modification, race contact surface finishing improvements, helps with lubrication when using gear and/or hydraulic oils.

For some applications, bearing housings might be made out of one material while the shaft will be composed of another type of material. In this case, the modifications to envelope dimensions and internal operating clearance help the bearing operate under temperature changes. These modifications give the bearing the proper fit and help maintain adequate running clearance.

No matter the heavy-duty truck or off-highway drive train application, Regal Rexnord has a bearing that will do the job. Beyond our wide range of cylindrical bearing configurations and sizes, Regal Rexnord can fully customize a bearing to meet your application needs.

The application engineers at Regal Rexnord regularly work with customers to meet their needs. For more information, visit the Regal Rexnord bearings page.
